Zapco HB 84D (D class) power amplifier (4-channel).
SKU: 50045
Zapco HB 84D (D class, RMS 4x120 W x 2 Ohm) power amplifier (4-channel).
Zapco HB 84D (D class, RMS 4x120 W x 2 Ohm) power amplifier (4-channel).
Features and functions - 4-Channel, Full Range, Class D - RCA and Speaker Level inputs - Variable input gain control - Variable electronic crossover Technical specification - Power @ 4Ω: 4 x 75 watts RMS - THD @ Rated Power < 0.5%THD - Power @ 2Ω: 4 x 120 watts RMS - Power Bridged @ 4Ω: 2 x 240 W RMS - Signal to Noise Ratio > 95dB - THD + Noise < 0.1% - Frequency Response 15Hz to 30KHz ±1dB - Input Sensitivity .25v to 6v (Low) - Dimensions (mm): 160 (L) x 115 (W) x 45 (H)
Features and functions - 4-Channel, Full Range, Class D - RCA and Speaker Level inputs - Variable input gain control - Variable electronic crossover Technical specification - Power @ 4Ω: 4 x 75 watts RMS - THD @ Rated Power < 0.5%THD - Power @ 2Ω: 4 x 120 watts RMS - Power Bridged @ 4Ω: 2 x 240 W RMS - Signal to Noise Ratio > 95dB - THD + Noise < 0.1% - Frequency Response 15Hz to 30KHz ±1dB - Input Sensitivity .25v to 6v (Low) - Dimensions (mm): 160 (L) x 115 (W) x 45 (H)
| Brand | Zapco |
|---|---|
| Weight | 4kg |
| By car brand | Universal (All brand) |
| Amplifiers by channels (+/- DSP) | 4-channel |
| Nominal Power RMS (4 Ω), W | 4 x 75 |
| Nominal Power RMS (2 Ω), W | 4 x 120 |
| Nominal Power RMS (Bridged, 4 Ω), W | 2 x 240 |
| Frequecy range (Hz) | 15 – 30000 |
| Signal/noise ratio, dB | 95 |
| Box Size (mm) | 160 (L) x 115 (W) x 45 (H) |
